스텐레스 후렌지 5kg/㎠ | 10kg/㎠ | 16kg/㎠ | 20kg/㎠ | 30kg/㎠ | 40kg/㎠ | 150Lbs, 300Lbs | 10-Bar | 16-Bar | 40-Bar | 6-Bar | 25-Bar | KSD 3578 | KSD 4308
16kg/㎠

Nominal
Pipe
Size
Outside
Dia of
Applica
bie
pipe
Inside
Dia of
Flange

∞
Outside
Dia of
Flange

o
Sectional Dimension of Flange
 Blot Hole
Appnox
Weight
(Kg)
t T Dia of Hub Rar
dus		 f g
a b Bolt circle
Diameter
C 		Number
Bolt
Holes		 Hole
Diameter		 Nominal
Blot
Size
10
15
20
25
32
17.3
21.7
27.2
34.0
42.7
17.8
22.2
27.7
34.5
43.2
90
95
100
125
135
12
12
14
14
16
16
16
20
20
22
26
30
38
46
56
28
32
42
50
60
4
4
4
4
5
-
-
-
-
-
-
-
-
-
-
65
70
75
90
100
4
4
4
4
4
15
15
15
19
19
M12
M12
M12
M16
M16
0.52
0.58
0.75
1.16
1.53
40
50
65
80
(90)
48.6
60.5
76.3
89.1
101.6
49.1
61.1
77.1
90.0
102.6
140
155
175
200
210
16
16
18
20
20
24
24
26
28
28
62
76
94
106
120
66
80
98
112
124
5
5
5
6
6
-
-
-
-
-
-
-
-
-
-
105
120
140
160
170
4
8
8
8
8
19
19
19
23
23
M16
M16
M16
M20
M20
1.64
1.83
2.58
3.65
3.95
100
125
150
200
250
300
114.3
139.8
165.2
216.3
267.4
318.5
115.4
141.2
166.6
218.0
269.5
321.0
225
270
305
350
430
480
22
22
24
26
28
30
34
34
38
40
44
48
134
164
196
244
304
354
138
170
202
252
312
364
6
6
6
6
0
8
-
-
-
-
-
-
-
-
-
-
-
-
185
225
260
305
380
430
8
8
12
12
12
16
23
25
25
25
27
27
M20
M22
M22
M22
M24
M24
4.94
7.00
9.62
12.1
20.0
24.4
350
400
450
500
(550)
600
355.6
406.4
457.2
508.0
558.8
609.6
358.1
409.0
400.0
511.0
562.0
613.0
540
605
675
730
795
845
34
38
40
42
44
46
52
60
64
58
70
74
398
446
504
558
612
646
408
456
514
568
622
678
8
10
10
10
10
10
-
-
-
-
-
-
-
-
-
-
-
-
480
540
605
660
720
770
16
16
20
20
20
24
33
33
33
33
39
39
M30*3
M30*3
M30*3
M30*3
M36*3
M36*3
35.0
46.2
61.9
73.25
88.1
98.8
650
700
750
800
850
660.4
711.2
702.0
812.8
803.6
664
715
766
817
868
895
960
1020
1095
1135
48
50
52
54
56
77
80
83
86
89
704
754
706
765
916
726
776
832
885
736
10
10
10
10
10
5
5
5
5
5
770
820
880
930
980
820
875
935
990
1040
24
24
24
24
24
39
42
42
48
48
M36*3
M39*3
M39*3
M45*3
M45*3
101
120
141
161
177
900
1000
1100
1200
914.4
1016.0
1117.6
1219.2
919
1021
1123
1225
1185
1320
1420
1530
58
62
66
70
93
99
105
112
968
1070
1180
1282
986
1098
1200
1302
10
12
12
12
5
5
5
5
1030
1140
1240
1350
1090
1210
1310
1420
28
28
32
32
48
56
60
68
M45*3
M52*3
M52*3
M52*3
191
230
289
348
